Max. Polyphony
64
Tones
Piano: 10 tones
E.Piano: 10 tones
Organ: 10 tones
Other: 10 tones (including a drum set)
GM2: 256 tones
(Settings can be changed only through the Roland Piano App.)
Master Tuning
415.3Hz - 466.2 Hz (adjustable in increments of 0.1 Hz)
Transpose
-6 - +5 (in semitones)
Ambience
(0--10, 5 types)
Brilliance
(-10--+10)
Only for Organ Tones
Rotary Speaker Effect
Piano Designer
Lid
Damper
Resonance
Single
Note Tuning
Single Note Volume
Temperament
Temperament Key
(Settings can be changed only through the Roland Piano App.)
Keyboard
88 keys (Ivory Feel and Box-shape Keys with velocity)
Key Touch
5 types, fixed touch
Speakers
12 x 6 cm (4-3/4 x 2-3/8 inches) x 2
Rated Power Output
6W x 2
Bluetooth Ver 5.0 Profile
A2DP (Audio)
GATT (MIDI over Bluetooth Low Energy)
CODEC
SBC (Supports SCMS-T content protection)
Compatible Android / iOS Apps
Roland Piano App*
Support for the app may be terminated without prior notice.
Recordable Software
Standard MIDI Files (Format 0, 1 part, Approx. 30,000 notes memory)
Internal Songs
10 songs
Convenient Functions
Metronome (adjustable Tempo/Beat/Volume, with Rhythm Pattern: 13 patterns)
Transpose (Keyboard: in semitones)
DualSplit (Settings can be changed only through the Roland Piano App. Split point adjustable)
Twin Piano
Speaker volume and Headphones volume automatically select function
Speaker Auto Mute
Auto Off
Connectors
DC In jack
Pedal jack (Capable of half pedal detection when optional pedal DP-10 connected)
USB Computer port: USB Type-C(R) (Class Compliant for Audio and MIDI)
Phones/Output jack: Stereo miniature phone type
Power Supply
AC adaptor or Alkaline battery (AA, LR6) / Ni-MH battery (AA, HR6) x 8*
Carbon-zinc batteries cannot be used
Current draw
400 mA (When using the included AC adaptor)
Power consumption when in OFF mode
(when the power automatically turns off)
0.2W
Battery Life for Continuous Use
Ni-MH batteries (AA, HR6): Approximately 7 hours (When using batteries having a capacity of 1,900 mAh.)
Alkaline batteries (AA, LR6): Approximately 6 hours*
This figure will vary depending on the actual conditions of use.
Accessories
Music Rest
Quick Start
List of Operations
Leaflet “USING THE UNIT SAFELY”
AC Adaptor
Power Cord
Option (Sold separately)
Keyboard Stand
KS-11Z, KS-13
Damper Pedal
DP-2 (Pedal switch)
DP-10 (Capable of half pedal)
Size and Weight
Without music rest
Width 1,280 mm / 50-7/16 inches
Depth 276 mm / 10-7/8 inches
Height 84mm / 3-5/16 inches
With music rest
Width 1,280 mm / 50-7/16 inches
Depth 309 mm / 12-3/16 inches
Height 245 mm / 9-11/16 inches
Weight excluding AC adaptor and music rest
5.8 kg / 12 lbs 13 oz
