Piano Sound
Piano Reality Modeling
Maximum Polyphony
Piano: Unlimited (when playing solo with grand piano tone)
Other: 256 notes
Tones
Total built-in tones: 54 tones
Selectable tones from the main unit: 6 tones (Grand Piano: 2, E. Piano: 2, Harpsichord: 1, Organ: 1)
Selectable tones from the Roland Piano App: 54 tones
*For data playback: 270 tones, GM2 compatible
Keyboard
PHA-50 Hybrid Keyboard (88-key hammer action keyboard) with escapement, white keys = ivory-feel finish, black keys = ebony-feel finish, High Precision Sensing
Pedal
Damper pedal (progressive damper action pedal, continuous
detection, damper modeling supported)
Soft pedal (continuous detection)
Sostenuto pedal
Speakers
12cm x 2, 5cm x 2
Rated Output
24W x 2
Headphones
Piano Reality Headphone Ambience Support
Cabinet
Music stand: fixed angle
Keyboard cover: foldable
Keyboard Touch
Key touch: 5 levels, fixed
Master Tuning
415.3 to 466.2 Hz (in 0.1 Hz increments)
Effects
Ambience, Brilliance
Piano Designer (only available via the Roland Piano App)
Key off noise
Hammer noise
Aliquot
Full Scale String resonance,
Damper resonance
Key-off resonance
Cabinet resonance
Soundboard type
Damper modeling
Single Note Tuning (stretched tuning)
Single Note Volume
Single Note Character
Tuning method: Tonic
Built-in songs
30 songs
Data playback
Standard Midi File (format 0, 1)
Audio files (requires USB memory, only USB memory of 32GB or
less is supported)
WAV format: 44.1 kHz, 16-bit linear
MP3 format: 44.1 kHz, 64 kbps to 320 kbps
Recorder
Standard Midi File (Format 0)
Number of songs: 1
Number of parts: 1 Parts
Recording capacity per song: Approximately 500 KB
Bluetooth
Standard specification Ver. 5.0
Supported profiles: A2DP (audio), GATT (MIDI over Bluetooth Low Energy)
Supported codec: SBC (supports content protection using the SCMS-T method)
Compatible applications (Roland)
Roland Piano App
Convenient Functions
Metronome (tempo/beat/strong beat/volume adjustable)
Transpose (semitone units)
Auto Off
Connectors
DC In jack
USB Mobile/PC port: USB Type-C (USB MIDI/Audio compatible)
USB Memory port: USB A
Phones jack x 2: Stereo mini type, stereo standard type
Power Supply
AC adapter
Power Consumption
17 W (when using the included AC adapter)
*Estimated power consumption when playing the piano with the volume set to the center: 8 W
*Power consumption after power-on when no sound is being played: 7 W
*Power consumption in off mode (when the power is automatically turned off): 0.3 W
Accessories
Owner's Manual
assembly leaflet,
"Safety precautions" leaflet,
"Handling of wooden products" leaflet,
AC adapter (PSB-14U),
power cord
headphone hook,
stabilizer (wooden device for preventing tipping)
dedicated pedals
dedicated height-fixed chair
External dimensions (piano: lid closed) *including stabilizer
Width 1,396 mm
Depth 382 mm
Height 783 mm
External dimensions (piano: lid open) *including stabilizer
Width 1,396 mm
Depth 382 mm
Height 910 mm
External dimensions (dedicated pedal)
Width 292 mm
Depth 216 mm
Height 95 mm
External dimensions (special fixed height chair)
Width 442 mm
Depth 302 mm
Height 520 mm
Weight
Piano 34.0kg
Dedicated pedal 2.1kg
Dedicated fixed height chair 4.7kg
